Sections
The extruded aluminum sections are manufactured from high-grade 6060 and 6063 alloy compositions, ensuring structural strength and precision. These profiles are engineered to meet system performance requirements and are suitable for anodizing, powder coating, or custom painting finishes.
Gasket
Both static and dynamic gaskets are made from EPDM (ethylene propylene diene monomer) for superior weather sealing and durability. Retention brushes are produced from high-density polypropylene with a central water-stripping feature to enhance drainage and prevent dust ingress.
Accessories
All accessories are precision-engineered and patented, using premium materials for long-term reliability. The sliding mechanism incorporates stainless steel ball bearings designed to handle maximum panel loads while ensuring smooth, quiet operation.
Glazing
The system supports glazing thicknesses from 12 mm to 38 mm, accommodating single, double, or triple glass units. Glass retention is achieved through internal and external EPDM gaskets, ensuring airtight sealing. Any incidental water infiltration is directed outward via integrated drainage channels within the system.
